编辑器拓展 Menuitem(编辑器组件)

编辑：rootadmin

using UnityEngine;using System.Collections;using UnityEditor ;public class MyEditorWindow : EditorWindow {[MenuItem ("Window/MyWindow")]static void AddWindow(){//创建窗口Rect rect = new Rect (0,0,,);MyEditorWindow window = (MyEditorWindow)EditorWindow .GetWindowWithRect (typeof(MyEditorWindow),rect,true,"CustomWindow");window.Show();}//输入文字类容；private string text;private Texture texture; string status="hao"; bool b;public int toolbarInt = 0;public Texture icon;public string[] toolbarStrings = new string[] {"Toolbar1", "Toolbar2", "Toolbar3"};public void Awake(){ //在资源中读取一张贴图 texture = Resources.Load ("1")as Texture;}//绘制窗口时调用void OnGUI(){// button 监听按钮EditorGUILayout .TextField ("name","value");if(GUILayout .Button ("点我"))Debug .Log ("点我了");Debug .Log ("OnGUI");EditorGUILayout.LabelField ("Status: ", "Idel");

推荐整理分享编辑器拓展 Menuitem(编辑器组件)，希望有所帮助，仅作参考，欢迎阅读内容。

文章相关热门搜索词:打开编辑器,扩充编辑栏,编辑器外观,编辑器组件,编辑器界面,编辑器界面,microsoft编辑器浏览器扩展,编辑器界面,内容如对您有帮助，希望把文章链接给更多的朋友！

EditorGUILayout.LabelField ("Empty");

//下拉隐藏菜单

b =EditorGUILayout .Foldout (b,status);if(b){EditorGUILayout.Vector3Field("Position", new Vector3 (0f,f,1f));}//输入框控件text = EditorGUILayout .TextField ("输入文字",text);if(GUILayout.Button ("打开通知",GUILayout .Width ())){//打开通知栏this.ShowNotification (new GUIContent ("This is a Notifactiion"));}if(GUILayout.Button ("关闭通知",GUILayout .Width ())){//关闭通知栏this .RemoveNotification ();}//文本框显示鼠标在窗口的位置EditorGUILayout .LabelField ("鼠标在窗口的位置",Event.current .mousePosition.ToString ());// 选择贴图texture = EditorGUILayout .ObjectField ("添加贴图",texture,typeof (Texture),true)as Texture;if(GUILayout.Button ("关闭窗口",GUILayout .Width ())){//关闭窗口this.Close ();} // 工具条toolbarInt = GUI.Toolbar(new Rect(, , , ), toolbarInt, toolbarStrings); // GUI.Button(new Rect(,, , ), new GUIContent("Click me", icon));}void Update(){}void OnFocus(){Debug.Log("当窗口获得焦点时调用一次");}void OnLostFocus(){Debug.Log("当窗口丢失焦点时调用一次");}void OnHierarchyChange(){Debug.Log("当Hierarchy视图中的任何对象发生改变时调用一次");}void OnProjectChange(){Debug.Log("当Project视图中的资源发生改变时调用一次");}void OnInspectorUpdate(){//Debug.Log("窗口面板的更新");//这里开启窗口的重绘，不然窗口信息不会刷新this.Repaint ();}void OnSelectionChange(){//当窗口出去开启状态，并且在Hierarchy 视图中选择游戏对象时调用 foreach (Transform t in Selection .transforms){ //有可能是多选,这里开启了一个循环打印游戏对戏的名称 Debug .Log ("OnselectionChange"&#;t.name); }}void OnDestroy(){Debug.Log("当窗口关闭时调用");}}
